Valve parameters：
Size:1/4”-2”
Pressure:1.6Mpa-6.4Mpa
Body Materials:Stainless Steel ,CF8,CF8M
Ball Materials:Stainless Steel ,CF8,CF8M
Seal Materials:PTFE
Connection:thread (BSP,BSPT,NPT)
Drive type:handle
Structure type:floating
Drawings and dimensions:
|
SIZE |
DN |
d |
L |
H |
W |
B |
ISO5211 |
□S |
|
1/4’’ |
6 |
4.2 |
64 |
32 |
85 |
32 |
F2 |
(7) |
|
3/8’’ |
10 |
6 |
64 |
32 |
95 |
32 |
F2 |
(7) |
|
1/2’’ |
15 |
10 |
68 |
34 |
108 |
34 |
F3 |
(9) |
|
3/4’’ |
20 |
15 |
78 |
60 |
115 |
39 |
F3 |
(9) |
|
1’’ |
25 |
18 |
86 |
60 |
135 |
43 |
F4 |
(9) |
|
1 1/4’’ |
32 |
25 |
111 |
76 |
150 |
55.5 |
F4 |
(11) |
|
1 1/2’’ |
40 |
32 |
126 |
85 |
175 |
63 |
F5 |
(11) |
|
2’’ |
50 |
40 |
143 |
95 |
190 |
71.5 |
F5 |
(11) |
